Allen Bradley 104-C23D22 belongs to the commutator contactor series. In China, Hanyite's product has achieved considerable sales and received positive feedback from customers. We have a customer base in Europe and the United States, and even more so in countries such as India, Southeast Asia, the Middle East, and Russia. Hannit offers high-quality products and first-class services. With a complete supply and sales channel as well as a strong professional team, we are committed to providing customers with the best service anytime and anywhere. As a safety contactor, the 104-C23D22 can be used for emergency stop control of dangerous moving equipment, such as CNC machine tools, packaging machinery and conveying systems, and complies with safety standards such as EN ISO 13849.
The Allen Bradley 104-C23D22 body is a sturdy plastic casing with clear terminal markings on it. The top is the main contact terminal connecting the main circuit, which is usually quite large and is used to connect thick cables. The control terminals and auxiliary contact terminals for connecting the control coil are located on the side or bottom. Inside, there is an electromagnetic coil. Once powered on, it generates magnetic force, which attracts an armature. The armature then drives the main contacts to close or open. Although the entire structure is not complicated, it has very high requirements for materials and craftsmanship.
|
Model |
AllenBradley104-C23D22 |
|
Series |
IEC 100S/104S Safety Contactor Bulletin |
|
Rated Current |
23A |
|
Numero di poli |
3-Pole (Main Contacts) |
|
Coil Frequency |
50/60 Hz |
|
Il corpo Allen Bradley 104-C23D22 è un robusto involucro di plastica con chiari contrassegni sui terminali. La parte superiore è il terminale di contatto principale che collega il circuito principale, che solitamente è piuttosto grande e viene utilizzato per collegare cavi spessi. I terminali di controllo e i terminali dei contatti ausiliari per il collegamento della bobina di controllo si trovano sul lato o sul fondo. All'interno c'è una bobina elettromagnetica. Una volta acceso, genera una forza magnetica che attrae un'armatura. L'armatura quindi guida i contatti principali per chiudersi o aprirsi. Sebbene l'intera struttura non sia complicata, presenta requisiti molto elevati in termini di materiali e lavorazione artigianale. |
220V |
|
Arc Quenching Medium |
Air |
|
Certifications |
SUVA Third-Party Certification compliant with CCC standard (3C Certificate No. for similar product: 2020970305001013) |
|
Rest Time |
18-23 ms (50% shorter than standard electronic coils) |
We need to consider load matching. The coil model should be selected based on the rated current (≤23A) of the controlled equipment and the power supply type (AC/DC). For example, Allen Bradley 104-C23D22 is the DC coil version. It can be used in conjunction with the Allen-Bradley 100S series auxiliary contact module to expand its functions. As a mature series of products, it shares some spare parts with other models in the same series (such as 104-C23EJ22 and 104-C23F22), reducing long-term maintenance costs.
